PX4FIBER

PX4FIBER is an octocopter drone developed by Bajrang UAV (OPC) Private Limited, an Ahmedabad-based UAV manufacturer specialising in custom drone applications. The platform is designed for applications requiring aerial operations, remote payload delivery and day-light aerial observation.

The PX4FIBER combines a compact 450 mm diagonal frame with a 2 kg maximum payload capacity and a transmission range of up to 10 km, depending on the attached reel.

Flight Performance

The PX4FIBER is specified with a maximum tilt angle of 55° in position hold mode and 35° in loiter mode. The proposal specifies speeds of 80 mph in position hold and 55 m/s in loiter.

Hover Accuracy

With Vision Positioning

• Vertical: ±0.1 m
• Horizontal: ±0.3 m

With GPS Positioning

• Vertical: ±0.5 m
• Horizontal: ±1.5 m

Payload Capability

PX4FIBER supports a maximum payload capacity of up to 2 kg, with the proposal specifically referring to a maximum dropping mechanism. This makes the platform suitable for missions requiring controlled aerial payload delivery.

Camera & Video

The platform is equipped with a day-light camera and provides video feed through an external mobile device or screen.

Operating Conditions

PX4FIBER is specified to operate across a temperature range of -10°C to 50°C and withstand wind speeds of up to 15 m/s. Its stated maximum service ceiling is 4000 m above sea level.
