PX6P2000

The PX6P2000 is a hexacopter UAV developed by Bajrang UAV (OPC) Private Limited. It is designed for autonomous aerial operations with VTOL capability, waypoint navigation, day/night imaging and payload-dropping capability.

Payload & Imaging

The PX6P2000 can carry up to 10 kg of payload and supports four release/drop mechanisms. Its imaging package includes a 4K daylight camera and 640 uncooled thermal camera, with 3-axis stabilisation and 6× zoom.

Communication

The UAV supports a communication link in the 4–5.1 GHz frequency band. Video transmission is specified at 1080p/60 fps for daylight and 640 thermal imaging, with a minimum of eight selectable channels or frequency hopping with encryption. Up to four quadcopters are specified for operation within the same geographical area of less than 5 km.

Product Highlights

28 kg Maximum all-up weight
10 kg Payload capacity
40 min Maximum endurance
5 km+ LOS control range
VTOL Take-off & landing
4K + Thermal Day/night imaging
